NOMINAL SIZE
A
B
C
T
mm
inch
mm
mm
mm
mm
25 x 6
1 x 1/8
19.1
7.7
28.5
6.4
25 x 8
1 x 1/4
19.1
7.7
28.5
8.2
25 x 10
1 x 3/8
19.1
7.7
28.5
9.2
32 x 8
1¼
x 1/4
20.4
8.7
28.5
8.2
32 x 10
1¼
x 3/8
20.4
8.7
28.5
9.2
32 x 15
1¼
x 1/2
20.4
8.7
34.1
11.0
40 x 8
1
½
x 1/4
21.1
9.4
28.5
8.2
40 x 10
1
½
x 3/8
21.1
9.4
28.5
9.2
40 x 15
1
½
x 1/2
21.1
9.4
34.1
11.0
40 x 20
1
½
x 3/4
20.4
8.7
41.4
12.7
50 x 8
2 x 1/4
22.4
10.5
28.5
8.2
50 x 10
2 x 3/8
22.4
10.5
28.5
9.2
50 x 15
2 x 1/2
22.4
10.5
34.1
11.0
50 x 20
2 x 3/4
22.4
10.5
41.5
12.7
50 x 25
2 x 1
22.4
10.5
49.6
14.8
65 x 15
2
½
x 1/2
27.2
11.2
34.1
11.0
65 x 20
2
½
x 3/4
27.2
11.2
41.5
12.7
65 x 25
2
½
x 1
27.2
11.2
49.6
14.8
65 x 32
2
½
x
1¼
27.2
11.2
60.8
17.1
80 x 15
3 x 1/2
29.0
12.2
34.1
11.0
80 x 20
3 x 3/4
29.0
12.2
41.5
12.7
80 x 25
3 x 1
29.0
12.2
49.6
14.8
80 x 32
3 x
1¼
29.0
12.2
60.8
17.1
80 x 40
3 x
1½
29.0
12.2
68.1
17.8
90 x 25
3
½
x 1
30.0
13.2
49.6
14.8
90 x 32
3
½
x
1¼
30.0
13.2
60.8
17.1
90 x 40
3
½
x
1½
30.0
13.2
68.1
17.8
90 x 50
3
½
x 2
30.0
13.2
83.4
19.1
100 x 25
4 x 1
31.0
15.3
49.6
14.8
100 x 32
4 x
1¼
31.0
15.3
60.8
17.1
100 x 40
4 x
1½
31.0
15.3
68.1
17.8
100 x 50
4 x 2
31.0
15.3
83.4
19.1
100 x 65
4 x
2½
31.0
15.3
98.1
23.4
125 x 50
5 x 2
33.3
15.3
83.4
19.1
125 x 65
5 x
2½
33.3
15.3
98.1
23.4
125 x 80
5 x 3
33.3
15.3
117.4
24.9
150 x 50
6 x 2
33.3
19.1
83.4
19.1
150 x 65
6 x
2½
36.0
19.1
98.1
23.4
150 x 80
6 x 3
36.0
19.1
117.4
24.9
150 x 90
6 x
3½
36.0
19.1
132.1
26.2
150 x 100
6 x 4
36.0
19.1
147.1
27.5
200 x 80
8 x 3
40.0
21.1
117.4
24.9
200 x 90
8 x
3½
40.0
21.1
132.1
26.2
200 x 100
8 x 4
40.0
21.1
147.1
27.5
200 x 125
8 x 5
40.0
21.1
179.1
30.0
